Odour trap for plastic shower drain

P065

Technical parameters

Odor trap combined with a water seal29 mm
Flow rate31 l/min
Resistance of odour trap against the pressure640 Pa

    Application

  • For linear shower drain APZ8, APZ9, APZ10, APZ18, APZ10BLACK

    Specifications

  • Combined odour trap SMART
Quantity (package) 1 pc
Quantity (pallet) - pc
Weight (piece) 0,0721 kg
Weight (package) 0,0721 kg
Weight (pallet) - kg

    Scope of supply

  • Odour trap
  • Seal 2 pcs
  • Ball 2 pcs
APZ10-550M Shower drain with an edge for perforated grids
APZ10-650M Shower drain with an edge for perforated grids
APZ10-750M Shower drain with an edge for perforated grids
APZ10-850M Shower drain with an edge for perforated grids
APZ10-950M Shower drain with an edge for perforated grids
APZ18-550M Shower drain with a stainless steel edge for perforated grids
APZ18-650M Shower drain with a stainless steel edge for perforated grids
APZ18-750M Shower drain with a stainless steel edge for perforated grids
APZ18-850M Shower drain with a stainless steel edge for perforated grids
APZ18-950M Shower drain with a stainless steel edge for perforated grids
APZ8-550M Shower drain with an edge for perforated grids
APZ8-650M Shower drain with an edge for perforated grids
APZ8-950M Shower drain with an edge for perforated grids
APZ9-550M Shower drain with an edge for perforated grids
APZ9-650M Shower drain with an edge for perforated grids
APZ9-750M Shower drain with an edge for perforated grids
APZ9-850M Shower drain with an edge for perforated grids
APZ9-950M Shower drain with an edge for perforated grids
Z0216-ND Ball brushed DN1.138"
Product codeEANTechnical sheet
File Name Size Action
icon P065 - CAD drawing.dwg 207.06 kB Download link icon
icon P065 - CAD drawing.dxf 578.48 kB Download link icon
