| The flow of the inlet grid (wet odour trap) | 50 l/min |
| Resistance of odour trap against the pressure | 480 Pa |
| Load class K3 | 300 kg |
| Waste pipe diameter | 50 mm |
| Total installation height | 87 mm |
| Odour trap | 15 mm |
Floor drain 105×105/50 mm side outlet, stainless steel grid, stainless steel flange and collar-2nd level insulation, combined odour trap SMART
APV3513
Product details
- For the interior, where will be frequent use associated with the regular water runoff into the floor drain (bathrooms) – combined odour trap
- For drainage of vinyl floors
- For wheelchair access
- Round grid Ø148 mm
- Wide insulation collar for connection to waterproofing construction
- Installation into vinyl floors
- Side connection to waste Ø50 mm
- Odour traps prevent the penetration of odours from the sewer
- Compatibility with floor drains parts including wet, dry and combined odour trap SMART
- Material: polypropylene resistant to mechanical, chemical and thermal damage
- Material: stainless steel AISI 304, DIN 1.4301
- EN 1253
| Quantity (package) | 1 pc |
| Quantity (pallet) | 120 pcs |
| Dimensions (piece) | 250×205×90 mm |
| Dimensions (package) | 250×205×90 mm |
| Weight (piece) | 1,2953 kg |
| Weight (package) | 1,2953 kg |
| Weight (pallet) | 175,436 kg |
- Floor drain body Ø50 mm, side outlet
- Stainless steel grid
- Combined odour trap
- Stainless steel flange + assembly set
- Seal kit
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| APV3513 | 8595580573430 |  |
