| Operating force | < 20 N |
| Output voltage | 12 V DC |
| Power consumption | 8,5 W |
Flush plate with sensor for pre-wall installation systems Slim, chrome-polished (AC power supply)
M371S-SLIM
Product details
- For pre-wall installation systems Slim and concealed WC cisterns Slim
- For touchless flushing with a sensor
- Powered by the main electric supply, the power source must be purchased (12 V DC min 1 A) – recommended AEZ310
- Setting via mini USB using free software available on the Alca website
- Adjustable parameters: start and end time of registration, duration of flushing, automatic flush, allowing flooding, flooding time, variable settings hygienic rinse
- Magnetic switch for service setting and cleaning
- Option to use the button for a large flush
- Surface finish: chrome-polished
- Material: plastic
- EN 55014, EN 55022, EN 61000
| Quantity (package) | 8 pcs |
| Quantity (pallet) | 128 pcs |
| Dimensions (piece) | 580×185×100 mm |
| Dimensions (package) | 590×390×430 mm |
| Weight (piece) | 1,9247 kg |
| Weight (package) | 15,3976 kg |
| Weight (pallet) | 266,3616 kg |
- Flush plate
- Infrared sensor
- Screw set with a solenoid valve
- Flush valve for sensor flushing
- Connector for attaching to the source
- Fixing frame of the flush plate
- Threaded frame clamp 2 pcs
| M0037-ND | Flush plate frame |
| M0042-ND | Flush plate frame spring |
| M0044-ND | Stopper |
| M1525ALCA-ND | Sensor for plastic flush plate - complete |
