| Height adjustment range | 315 – 450 mm |
| Functional requirements class I | |
| Flush volume of single flushes is determined by the size and the volume of the tank | |
| Acoustic group II | <30 dB |
| Working range | 0,05 – 0,8 MPa |
| Recommended operating pressure | 0,3 – 0,5 MPa |
| Quantity (package) | 16 pcs |
| Quantity (pallet) | 256 pcs |
| Dimensions (piece) | 400×200×100 mm |
| Dimensions (package) | 590×430×390 mm |
| Weight (piece) | 0,7754 kg |
| Weight (package) | 12,4064 kg |
| Weight (pallet) | 218,5024 kg |
| N0023-ND | Nut G3/8" white |
| N0031-ND | Conical sealing 30×16,5×3 |
| V0056-ND | Sealing 115×70×15 |
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| SA08AS 3/8" CHROM | 8595580532840 |  |
