| Odour trap | 58 mm |
| Flow rate | 38 l/min |
| Thermal resistance | 95 ˚C |
| Hose connector | 17 – 23 mm |
Product details
- For wash-basin
- Connection to waste pipe Ø32 mm
- With connector for washing machine or dishwasher
- Material: polypropylene
- EN 274
| Quantity (package) | 25 pcs |
| Quantity (pallet) | 700 pcs |
| Dimensions (piece) | 220×80×140 mm |
| Dimensions (package) | 590×240×390 mm |
| Weight (piece) | 0,2366 kg |
| Weight (package) | 5,915 kg |
| Weight (pallet) | 185,62 kg |
- Sink trap body with connector
- Plastic rosette
- Nut to connect wash-basin waste 5/4"
| P0050-ND | Washer + flap |
| P061-ND | Pipe DN32 with rosette |
| S0006-ND | Rosette DN40 |
| S0007-ND | O-ring 58×2 |
| S0013-ND | Trap grid 5/4" stainless steel |
| S0016-ND | Sealing 60×45.5×2 |
| S0309-ND | Screw M6×80 stainless steel |
| S0321-ND | Rosette DN32 |
| S0336-ND | Conical sealings white |
| S0442-ND | Sealing 39×30×4 |
| S0955-ND | Rosette DN32 |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| A430P | 8594045937008 |  |
