Washing machine pipe trap DN50

APS7-DN50

  • For connecting a washing machine
  • Hose connection Ø19 and Ø23 mm
  • Connection to waste pipe Ø50 mm
  • Material: ABS
  • EN 274
Quantity (package) 15 pcs
Quantity (pallet) 420 pcs
Dimensions (piece) 350×120×60 mm
Dimensions (package) 580×380×230 mm
Weight (piece) 0,3318 kg
Weight (package) 4,977 kg
Weight (pallet) 159,3560 kg
  • Waste and trap body
  • Rosette
  • Connector
File Name Size Action
icon APS7-DN50 - Installation instructions.pdf 188.57 kB Download link icon
icon APS7-DN50 - CAD drawing.dwg 194.36 kB Download link icon
icon APS7-DN50 - CAD drawing.dxf 507.49 kB Download link icon
icon Product code Ean Technical sheet
icon APS7-DN50 8595580586041 Download Download
