| Odour trap | 50 mm |
| Flow rate | 48,6 l/min |
| Overflow flow rate | 33,6 l/min |
| Resistance of odour trap against the pressure | 588 Pa |
| Thermal resistance | 95 ˚C |
Bath CLICK/CLACK waste and trap, overflow filler, for thick-walled bathtubs, chrome
A509CKM
Product details
- For filling the bath by overflow
- To drain the water from the bath to the waste
- For thick-walled bathtubs
- For bathtubs with drain outlet Ø52 mm
- Bath overflow filler, waste and trap system
- Aerator Neoperl – easy access and exchange
- Control shaft made of stainless steel
- Water does not flow down on the side of the bathtub and does not leave marks
- Space-saving design in the bathtub – only control knob visible
- Easy installation with three stainless steel screws
- Wet odour trap with swivel elbow
- Closing waste by CLICK/CLACK
- Overflow flexi pipe
- Side G1/2" fitting for filling of pre-mixed water
- The length of the bathtub trap 57 cm
- Easy clean trap – thanks to completely removable waste outlet
- EN 274
| Quantity (package) | 12 pcs |
| Quantity (pallet) | 192 pcs |
| Dimensions (piece) | 380×95×210 mm |
| Dimensions (package) | 595×435×395 mm |
| Weight (piece) | 0,9855 kg |
| Weight (package) | 11,826 kg |
| Weight (pallet) | 209,216 kg |
- Waste and trap body with overflow
- Chrome-plated plastic control knob
- Chrome-plated metal plug
- Chrome-plated brass outlet
- Odour trap of polypropylene, thermally and chemically resistant, longitudinally welded
- Assembly kit
- Profiled seal
| S0008-ND | Conical sealing 36×31,5×5 |
| S0036-ND | Key for shower waste and trap |
| S0036K-ND | Universal key, metal |
| S0085-ND | Sealing 70×50×6 |
| S0090-ND | Sealing 70×50×2 |
| S0437-ND | Trap drain CLICK/CLACK |
| S0525-ND | CLICK/CLACK mechanism |
| S0751-ND | Bathtub siphon insert |
| S1182-ND | Conical sealing 38×30×7 |
| S1425A-ND | Bathtub outlet CLICK/CLACK 6/4" |
| S1522-ND | Key for bath trap outlet 6/4" |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| A509CKM | 8595580567088 |  | ||
| A509CKM-80 | 8595580567118 | | ||
| A509CKM-100 | 8595580567095 | | ||
| A509CKM-120 | 8595580567101 | |
