| Odour trap | 50 mm |
| Flow rate | 48,6 l/min |
| Overflow flow rate | 27 l/min |
| Resistance of odour trap against the pressure | 588 Pa |
| Thermal resistance | 95 ˚C |
Product details
- To drain the water from the bath to the waste
- For standard size bathtubs
- For bathtubs with drain outlet Ø52 mm
- For design thin-walled freestanding bathtubs
- Bath waste and overflow system
- Wet odour trap with swivel elbow
- Closing waste by CLICK/CLACK
- Overflow flexi pipe
- Reduced installation height
- The length of the bathtub trap 57 cm
- Easy clean CLICK/CLACK
| Quantity (package) | 20 pcs |
| Quantity (pallet) | 320 pcs |
| Dimensions (piece) | 220×360×75 mm |
| Dimensions (package) | 590×430×390 mm |
| Weight (piece) | 0,7118 kg |
| Weight (package) | 14,236 kg |
| Weight (pallet) | 247,776 kg |
- Waste and trap body with overflow
- Chrome-plated metal grid and overflow cover
- Chrome-plated metal plug
- Chrome-plated brass outlet
- Odour trap of polypropylene, thermally and chemically resistant
- Assembly kit
- Profiled seal
| P172-ND | Overflow body incl. cover chrome |
| S0003-ND | Nut G1 1/4" |
| S0004-ND | Nut G1 1/2" |
| S0009-ND | Conical sealing 44×39×5 |
| S0437-ND | Trap drain CLICK/CLACK |
| S0447-ND | Shaped sealing white |
| S0513-ND | Sealing under plug for CLICK/CLACK |
| S0525-ND | CLICK/CLACK mechanism |
| S0986-ND | Plug CLICK/CLACK 6/4" metal |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| A516CKM | 8595580561826 |  | ||
| A516CKM-80 | 8595580561888 | | ||
| A516CKM-100 | 8595580561864 | | ||
| A516CKM-120 | 8595580561871 | |
