| Odour trap | 50 mm |
| Flow rate | 34 l/min |
| Thermal resistance | 95 ˚C |
Product details
- For wash-basin
- Connection to waste pipe Ø32 mm
- High scratch resistance
- Material: chrome-plated metal
- EN 274
| Quantity (package) | 20 pcs |
| Quantity (pallet) | 560 pcs |
| Dimensions (piece) | 325×120×60 mm |
| Dimensions (package) | 590×240×390 mm |
| Weight (piece) | 0,6033 kg |
| Weight (package) | 12,066 kg |
| Weight (pallet) | 357,848 kg |
- Waste and trap body
- Nut to connect wash-basin waste 5/4"
- Metal rosette
| S0017-ND | Sealings 39×28×2 |
| S0515-ND | Friction ring DN32 |
| S0950-ND | Rosette for A431 |
| S1523-ND | Shaped sealing for washbasin traps |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| A431 | 8594045930665 |  |
