| Odour trap | 64 mm |
| Flow rate | 60 l/min |
| Thermal resistance | 95 ˚C |
Product details
- For wash-basin
- To save space under the wash-basin
- Connection to waste pipe Ø40 mm
- Material: polypropylene
- EN 274
| Quantity (package) | 12 pcs |
| Quantity (pallet) | 336 pcs |
| Dimensions (piece) | 330×90×210 mm |
| Dimensions (package) | 590×240×390 mm |
| Weight (piece) | 0,3773 kg |
| Weight (package) | 4,5276 kg |
| Weight (pallet) | 146,7728 kg |
- Waste and trap body
- Plastic rosette
- Nut to connect wash-basin waste 5/4"
| S0004-ND | Nut G1 1/2" |
| S0006-ND | Rosette DN40 |
| S0009-ND | Conical sealing 44×39×5 |
| S0323-ND | Sealing 45×37×3 |
| S0442-ND | Sealing 39×30×4 |
| S0516-ND | Friction ring DN40 |
| S0956-ND | Rosette DN40 |
Downloads
| Product code | EAN | Technical sheet | ||
|---|---|---|---|---|
| A434 | 8595580503086 |  |
